Specifications
Cutting Area:1300X3000mm
Cutting Speed:40m/min
Graphic Format Supported:AI, PLT, DXF, DXP
Application:Laser Cutting
Condition:New
Cutting Thickness:3mm S.S 6 mm CS
CNC or Not:Yes
Cooling Mode:Water Cooling
Control Software:Au3tech
Place of Origin:Guangdong, China (Mainland)
Brand Name:XQL
Certification:CE, ISO
Warranty:2 Years
Transmission System:Double Driver Transmission
Cooling Way:Water Cooling
Laser generator:RAYCUS
Power:500W
Power supply:220V/50HZ
The whole machine power:7 KW
Auxiliary equipments:gas / air compressor
The Max Running Speed:40 m/min
Max Cutting Speed:15m/min (up to material thickness,machine power)
Accelerated Speed:0.6G
| Working size | Width:1300mm/1500 mm Length:3000 mm |
| Power | 500 Watt / 750 Watt |
| Laser cutting control system | AU3TECH / CYPCUT (OPTION) |
| Laser Cutting Head | AU3TECH Cutting Head / Raytools(option) |
| Servo Motor | Delta |
| Driver | Delta |
| Reducer | Delta |
| Gear Rack | Germany |
| Guide Rail | Taiwan |
| Laser generator | MAX / RAYCUS |
| Positioning Accuracy | <0.1mm/m |
| The Best Running Speed | 0-15m/min |
| The Max Running Speed | 40 m/min |
| Accelerated Speed | 0.6G |
| Cooling Way | Water Cooling |
| Transmission System | Double Driver Transmission |
| Power supply | 220V/50HZ |
| Applicable material | Stainless Steel/ galvanized sheet/carbon steel and others metal |
| The whole machine power | 500W-7KW 750W-9KW |
| Max Cutting Thickness | 500W-Stainless Steel 3 mm Carbon Steel 6 mm 750W-Stainless Steel 4 mm Carbon Steel 10 mm |
| Auxiliary gas | nitrogen /Oxigen/Air compressor |
Cutting Parameter
Auxiliary gas:
(You can choose one of the both of gas and air compressor)
1.Nitrogen gas
(stainless steel plate processing gas purity of at least 99.6% or more) Oxygen gas
(carbon steel galvanized plate processing gas purity of at least 99.6% or more)
Gas | Purity | |
Oxygen | 99.5% | |
Nitrogen | 99.5% |
- High pressure air (no water, no oil), minimum pressure 1.3MpaPlease according to the configuration standard to purchase if you are using the compressed air:
Air Compressor (It will save more cost for using air compressor, but the cutting result, gas is more better than air compressor ) | Conforms to the ISO08573-1 standard. Maximum particle size:5μm Maximum content of Agglomerate: 5mg/M3 Maximum oil content: 0.1mg/M3 Minimum air volume:1M3/min Minimum output pressure:1.3 Mpa |
Application:
1.Applicable Industry:advertising,sheet metal processing, bathroom spare parts,
door decoration, hardware, electrical appliances, textile machinery, ships,
household appliances, kitchen,metal and other processing industries etc
2.Applicable material:stainless steel, carbon steel,galvanized sheet,copper,aluminum etc
Our Service:
Training and installation(we can provide 2 ways):
- The first way:you can come to our factory for training.we will offer professional guide.Direct and effective face-to-face training.
- The second way:our engineer will do a door-to-door instruction training service at your local site.but buyer is responsible for our engineer 's round trip ticket,visa fee , hotel , food,training fee etc
- All the machines will be tested and adjusted as per requirements before shipping.
- Warranty: 1 year for the machine(excluding consumption)
- Terms of payment: 30% deposit by T/T , the balance should be paid before delivery.
- Delivery time: 30 days after we get the down payment.Advantage:Cost advantage:
1.It can cut sheet metal by Air compressor.
2.Lifespan is 100,000 hours.
3.Laser source 2years warranty.
4.Easy control system.
Environmental Protection and Energy Saving
1.Higher electro-optical conversion rate: fiber cutting machine’s electro-optical
conversion rate about 30%, it is 3 times higher than co2 fiber cutting machine.
2.Higher cutting speed and efficient,2 time faster than YAG or CO2 laser.
3.Low cost: Machine power consumption is 20% -30% of same power co2 laser
cutting machine , every hour consumed 0.5w to 1.5 w electricity,it is very easy to
maintain: no need to adjust optical path.
