Specifications
Engraving Speed:30000mm/min
Graphic Format Supported:AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Application:Laser Engraving
Engraving Area:1300*2500mm
ConditionNew
CNC or Not:Yes
Cooling ModeWater Cooling
Place of Origin:Anhui, China (Mainland)
Certification:CE, ISO, SGS
Warranty:1 Year
Laser source:Raycus Fiber Laser
Control systemCyo Tube
Chiller:TEYU
ReducerShimpo reducer
Fiber laser head:Ray tools
Auxiliary gas:Air, oxygen,nitrogen
Cutting speed:Depending on materials
Aiming pisition:Red light
Bed structure:Welded thick square pipes
Motor and driver:YASKAWA
Product Description
Certification: ISO9001, SGS, CE
Product Name | genius-KJG-1530D 500w fiber laser cutting machine Manufacturer Direct Selling High Quality Fiber Laser Cutting Machine |
Material of bed structure | Welded thick steel pipes |
Color | blue & white |
Working area | 1300*2500(mm) |
Fiber laser power | 500w |
Laser wavelenghth | 1080nm |
Beam quality | <0.373mrad |
Cutting accuracy | ±0.05mm |
Repositioning accuracy | ±0.03mm |
Max. Working speed | 30000mm/min |
Cutting speed | Depending on materials |
Auxiliary gas | Air, oxygen, nitrogen. |
Cooling mode | Industrial recycled cooling water |
Aiming positioning | Red light |
Continuous working hours | 24H |
Laser source | Raycus |
Control system | CypTube |
Fiber laser head | Ray tools |
Bed structure | Welded thick square pipes |
Motor and driver | YASKAWA |
Guide rails | PMI guide rails |
Racks | Taiwan YYC racks |
Chiller | TEYU |
Oiling system | Auto lubricating system |
Reducer | Japan Shimpo reducer |
Laser source
The single core junction semiconductor pumped laser is used as the pumping source of the fiber laser. The fiber laser has the characteristics of long life. Minimum service life exceeds 100,000 hours.
It has excellent thermal performance, high electro-optical efficiency, water saving and electricity saving. Especially important, it can be used without maintenance for a long time. It can save a lot of maintenance funds and time, and improve work efficiency.
Fiber laser head---Ray tools
It has Z-axis follow-up function. Stable and fast cutting height automatic adjustment function. Various nozzle matching designs are suitable for lenses with various focal lenses. Optical lenses with different focal lengths can be equipped. The focal length and nozzle height can be adjusted flexibly, including X-Y lens and nozzle coaxial adjustment. The focal length of cutting head can be adjusted to 0.01mm accurately.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 10-15 days if the goods are in stock. or it is 15-20 days if the goods are not in stock.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact me.
