Specifications
Cutting Area:3000mm*1500mm
Cutting Speed:0-40000mm/min, 72m/min
Graphic Format Supported:BMP, DST, DWG, DXF, DXP, LAS, PLT
Application:Laser Cutting
Condition:New
Cutting Thickness:0~6mm
CNC or Not:Yes
Cooling Mode:Water Cooling
Control Software:LASER Control System
Place of Origin:Anhui, China (Mainland)
Certification:CCC, SGS, UL
Warranty:3 years
Model Number:KJG-1530DT
Laser type:IPG fiber laser generator
Y-axis travel:3000mm
Laser wavelength:1070nm
Format supported:AI, DST, DWG, DXF, DXP, LAS
Laser power output rating:1000W
Total Power consumption:15KW
Product Description
• Manufactured by people who use their own machines.
• The resonator comes with a 100,000 hour warranty from the manufacturer (IPG)
• Higher cutting speeds possible
• Dual interchangeable tables allow for faster loading and unloading, reducing downtime
• Laser wavelength is one-tenth of a CO2 laser
• Reduction in cutting variables or tribal knowledge
• Fiber Laser is extremely efficient, equates to very low power consumption
• Low cost of operation, energy cost reduced, no laser gases requied to produce beam
• High cutting flexibility (Steel, Stainless Steel, Brass, Copper, Titanium, Aluminum, and more)
• Laser beam transmitted through a fiber optic.cable rather than with mirrors and channel tubing resulting in negligible power loss.
• Created and tested in a 100,000 sq ft Research and Development facility operating 9 metal cutting fiber Lasers, cutting 24/7.
Main Features
• Acceleration speed: 19,6 m/s2 (2G).
• Maximum simultaneous positioning speed: 160m/min.
• Precision: + - 0.05 mm.
• Energy efficiency: greatly reduced power consumption.
• Excellent cutting quality for fine thic kness and medium thickness sheet metals.
• IPG Resonator. Power output from 1 kw to 6 kw .
• Precitec light cutter cutting head with po wer output up to 2kw.
• Precitec HP cutting head for po wer output of more than 2kw.
• Fully enclosed and cabinned to ensur e máximum operator protection.
• Effective high to low pressure gas exchange system.
• Capacitative Sensor, high pressure cutting head.
• TCI Cutting parameter tables.
• Pre-cut film protector.
• Automatic mechanized Nesting power output control function (edges, start-ups).
• Automatic time and unit cost calculation function.
• Network connection from external.
• Automatic table exchanger (included in series models).
• Smoke extraction (included in series models).
• 3 point reference sensor (sheet metal rotation detector).
• Piercing Sensor.
• Collection of work pieces and trimmings.
• Dual proportional valve control system for different gas pressures and special system for high pressure cutting.
