Specifications
Cutting Area:2500x1300mm
Cutting Speed:120m/min
Graphic Format Supported:AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Application:Laser Cutting
Condition:New
Cutting Thickness:1-30mm
CNC or Not:Yes
Cooling Mode:Water Cooling
Control Software:Bochu
Place of Origin:Anhui, China (Mainland)
Brand Name:ACCURL
Certification:CE
Warranty:3 years
Working area:1300X2500MM
Laser power2000W / 3000W/400W
Control system:Bochu
Driving system:Yaskawa Servo Motor
Positioning Accuracy:0.01mm
Cooling system:Water Chiller
Lubrication system:Full-automatic
auxiliary gases:Oxygen, Nitrogen
Power supply:AC 380V 3-phase 50Hz/60Hz
Product Description
Features:
1. High-rigidity heavy chassis, reducing the vibration generated during high-speed cutting greatly.
2. Gantry double-drive structure with imported German rack & pinion transmission system, improved the production efficiency.
3. High-performance cast aluminium guide rail, after finete element analysis, realized highly accelerated speed circular arc cutting.
4. Fiber laser system, good optical patch,smaller gap, high precision.
5. Imported cutter head, keep laser focus stable distance.
6. Double liner guide, ball screw transmission, higher speed, high precision and high performance.
7. Imported Yaskawa servo motor and gearing system to guarantee precise cutting.
8. Dedicated software enables graphic or text to instantly designed or processed, flexible and operation.
Parameter
| Working area | 2500x1300mm | 3000x1500mm |
| Laser type | Fiber laser generator | |
| Laser power | 500W/750W/1000W/1500W/2000W/3000W/4000W | |
| Transmission system | Gantry double –drive structure | |
| Lubrication system | Full-automatic | |
| Control system | Bochu | |
| Motor drivers | Yaskawa servo motors | |
| Maximum speed | 170m/min | |
| Maximum Cutting Speed | up to 120 m/min | |
| Minimum Line Cutting Width | 0.1mm | |
| Position accuracy | ±0.01mm | |
| Reposition accuracy | ±0.01mm | |
| Graphic format supported | CAD,DXF (etc) | |
| Quantity of pallets | at least 2 pcs | |
| Max. load on the table | 920 kg | |
| Consumed auxiliary gases when cutting metal | Air, Oxygen, Nitrogen | |
| Working environment | Temp: 0-40℃, humidity: ≤80%, No condensation | |
| Total power | Around 20KW | |
| Power supply | AC 380V 3-phase 50Hz/60Hz | |
Applicable industry :
Widely used in sheet-metal structure, high-low-voltage electrical cabinet production, kitchen ware, hardware, metal cabinets, auto parts.
production of advertising signs, metal crafts, decoration aviation, mechanical parts, electrical meter, saw blades, spring-chip and other industries.
Application material:
Metal materials such as carbon steel, stainless steel, aluminum alloy, titanium alloy, galvanize sheet, brass, red copper etc.
FAQ
Q1: How do I know if the machine is suitable for me?
You can tell us your working material,effect pictures or video, we shall judge if our machine meet your working requirements. After then we will recommend a suitable model and machine configuration to you as your working requirements.
Q2: I never use this kind of machine before, is it easy to learn and operate?
The user manual in English and operation video will be sent come with the machine. If there is still any questions, we can help you by "Teamviewer" online software, also you talk through phone or Skype.
Moreover, you can come to our factory to learn how to use it before shipment. Our technician will give you professional guidance.
Q3: What's the guarantee and after-sale service?
1. One year guarantee for whole machine and lifetime free technical support. After the warranty period, the consumable parts will be charged at cost price.
2. 24 hours technical support by e-email, Skype, WhatsApp, Wechat or calling.
3. Free training on our plant.
4. Lifetime maintenance free of charge.
Q4: How is the packing?
1. Inner package: Water-proof Stretch film package with foam protection in each corner.
2. Outside package: Solid seaworthy export plywood Box package with Steel Belt.
Q5: What is your delivery time? (production procedure)
1. For standard machines, it would be 20 days;
such as 3 axis machine with standard configuration, about 20 days.
2. For non-standard machines and customized machines according to client's specific requirements, it would be 50 - 90 days.
4 axis machine with standard configuration, about 50-60 days.
5 axis machine with non-standard configuration, about 80-90 days.
Q6: What payment method do you accept?
1. T/T: 30% in advance.
2. Western Union: only for small payment( below USD3000),but the bank charges shall be paid by buyer.
3. L/C is acceptable if the amount is big.
Q7: Do you arrange shipment for the machines?
If FOB or CIF price, we will contact shipping forwarder and deliver the goods to your country. If EXW price, clients need to arrange shipment by themselves or their agents.
Yes, we will arrange shipment whatever FOB or CIF price, the we will contact shipping forwarder and deliver the goods to your country. But if EXW price, clients need to arrange shipment by themselves or their agents.
Q8: How about the documents after shipment?
After shipment, we will send all original documents to you by TNT or DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
