Specifications
Cutting Speed:80m/min
Graphic Format Supported:AI, DXF, PLT
Application:Laser Cutting
Condition:New
Cutting Thickness:Carbon steel 5mm
CNC or Not:Yes
Cooling Mode:Water Cooling
Control Software:CYPCUT
Place of Origin:Anhui, China (Mainland)
Model Number:YH-2513G
Certification:CE
After-sales Service Provided:Engineers available to service machinery overseas
Introduce | ||||||||
| 1. Adopt the most advanced fiber laser outputs high energy density of the laser beam, and gathered on the surface of the workpiece, the upper region of the workpiece is instantaneously melted and gasification ultrafine focus spot irradiated by CNC machine system for mobile spot irradiation position automatically cutting | ||||||||
| 2. Adopt gantry structure type, bilateral drive with rack and pinion, with structural stability, good rigidity, high speed characteristics, its positioning speed up to 80m / min. | ||||||||
| 3. Lathe bed is the multiple aging tratment welding part, transmission parts such as gear, gear rack rails and adopt foreign imported brands, and its overall structure and transmission mode gantry rack and pinion positioning device ensures high-speed, fast dynamic response and good stability, represents the direction of the laser cutting machine development. | ||||||||
Product advantages | ||||||||
| 1. Professional laser optical system and import lens, stable and reliable. | ||||||||
| 2. Highly efficient and stable programming and control systems, easy to learn user-friendly, compatible with a variety of CAD drawing formats, intelligent nesting to save costs, automatic cutting path (donated automatic nesting software set) matching save processing time. | ||||||||
| 3. Less energy consumption, low cost; equipment with high stability, easy maintenance, with low maintenance costs. | ||||||||
| 4. Without molds, flexible processing, can meet the requirements of various shaped workpieces. | ||||||||
| 5. High cutting efficiency, high cutting quality, no noise; high speed, high efficiency, cut sheets per minute up to 30 meters; good cutting edge quality, small deformation, smooth appearance, beautiful. | ||||||||
| 6. Imported high-precision servo motor, rail, rack and pinion German origin, in ensuring the processing efficiency and precision, while greatly improving the stability and reliability of equipment operation. | ||||||||
Application industrial | ||||||||
| metal cutting, electrical switch manufacturing, aerospace, food machinery, textile machinery, engineering machinery, locomotive manufacturing, agriculture and forestry machinery, elevator manufacturing, special vehicles, household appliances manufacturing, processing tools, IT manufacturing, oil machinery manufacturing, food machinery , diamond tools, welding, welding gear, metal surface treatment, decorative advertising, laser processing of external services and other kinds of machinery manufacturing and processing industries. | ||||||||
Applicable material | ||||||||
| Professional for cutting a variety of thin sheet metal, high-quality carbon steel plate cutting 0.5-6mm also cut stainless steel plate, aluminum plate, galvanized sheet, electrolytic plate, silicon steel, titanium, galvanized plate and other metallic material | ||||||||
Configuration parameters | ||||||||
| 1. Mechanical motion system: Bilateral drive beam structure, including the basic structure of the body and the bed beam, main beam structure of the main body driving height compensation structure and organization. X, Y direction of movement of both ends of travel limit switches control travel, supplemented on both sides of the elastic cushion. Transmission components such as gearboxes, guide rails and rack and pinion are made of imported brands. | ||||||||
| 2. Control System: Using a special CNC laser cutting system with a high degree of reliability and stability, it has gradually developed and refined form the most simple system. Specific functions are as follows: 1) Professional laser cutting operating system, multi-language (including Chinese) interface, easy to operate. 2) AC servo drive system and AC servo motor, reliable performance, fast response, maintenance-free. 3) Fast response surface to follow. 4) easy to operate cutting retract function. 5) linear / circular interpolation and cutting compensation function. 6) with USB and broadband access, facilitate the realization of laser cutting machine communication, file transfer. 7) equipped with professional laser cutting automatic programming software, the software has manual or automatic nesting sets of cutting function. |
| 3. The world's advanced fiber laser | ||||||||
Main features | ||||||||
| 1. Excellent beam quality (BPP), full power within a constant BP, using a long focal length can still get a very small spot. | ||||||||
| 2. specific wavelength (1070nm), has a cut such as aluminum, copper, brass, highly reflective material unique ability. | ||||||||
| 3. laser electro-optical conversion rate of> 25%, much larger than the CO2 (<10%), significantly reducing the power loss. | ||||||||
| 4. laser through the optical fiber transmission, almost no transmission loss. | ||||||||
| 5. Modular design, "plug and play" compact, easy to install, without the need for laser and beam delivery system maintenance. | ||||||||
| 6. pumping source service life> 100,000 hours | ||||||||
| 7. Precise beam quality, with a small divergence angle |
