Specifications
Cutting Area:6000*200mm
Cutting Speed:70m/min
Graphic Format Supported:AI, PLT, DXF, DWG, DXP
Application:Laser Cutting
Condition:New
Cutting Thickness:20mm
CNC or Not:Yes
Cooling Mode:Air Cooling
Control Software:PA 8000
Place of Origin:Anhui, China (Mainland)
Brand Name:ACCURL
Certification:CE
Warranty:1 Year
Product name:laser cutting machine
Laser power:1000w
Function:pipe cutting
Type:white and blue
Control system:siemens
Working area:4000mm*3000mm*1000mm
Laser source:Germany IPG Fiber Laser
Product Application
Application Materials: Fiber Laser Cutting Equipment is suitable for metal cutting with Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring Steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc
Application Industries:Fiber Laser Cutting Machines are widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts, Nameplates, etc.
Working Table
1. High precision CNC fixed working table
2. Special designed small pneumatic wheel carriers ,the metal sheet to be cut may slide along the machine body for easy loading
3.Strip working table; Al material,put cutting sheet on it
Fiber Laser Generator
1. Fiber Laser Module
2. Low Energy Consumption: Save energy and protect environment
3. Photoelectric conversion rate is up to 25-30%
4. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine
5. Lifetime is more than 100,000 hours
6.Almost free maintenance
Optical System
1. Fiber transmission, no need to adjust reflect mirrors, optical path and laser source
2.Laser beam is fixed and only focused by one focus mirror to the cutting material surface
Automatic Focusing Height Follower:
1.USA improved technology and adopt China patents, automatic sensor senses the capacitance from the tip of the isolated cutting nozzle to the metal being cut. This data is then fed into the Height Follower Controller
2.If the metal sheet have wavy surfaces, the focus height follower can ensure constant distance between the focal lens and the plane of the metal sheets to be cut, so that consistent cutting quality can be achieved
3.It can avoid defects caused by wavy metal surfaces and also avoid the damage of the nozzle head.
Laser Head With Anti-Crash Function, Good sealed, high pressure resistant, auto-tracking system and anti-crash and stop system can protect good cutting quality and longer the life of lens
Drive System
1. Schneider servo motor system (made in France) ensures the possibility of realizing extreme precise positioning with the excellent dynamic response acceleration property and closed loop control method, and that makes moving positioning mechanism operate smoothly, reliably and free of maintenance
2. Servo motors in X,Y,Z, Rotary axis
3. Location accuracy: ≤±0.04mm
Guide Rail
Rack and Pinion drive
1. Strong bearing capacity
2. Fast moving speed
3. High positioning accuracy
4. Large power for transmission
5.Long-life, Maintenance-free, Smooth operation, High reliability
Reduction Gear
Installed on X/Y axis. It can protect the transmission system and keep the smooth operation of the machine.
Control System:
Standard industrial PC, easy operation
Laser Power Supply System:
1. Laser power supply adopts the latest switching power supply
2. It consists of main circuit, control circuits, circuit protection, pre-ignition and maintain circuit with the flow, the pressure, water flow protection device
3.Alarm Light to warn operator and others to notice that the machine is working.
Cooling System
Water cooling system, the temperature of the refrigeration unit in digital chart shows, while water temperature more than a specified temperature, it will automatically refrigeration; while water temperature below a specified temperature it will automatically stop.
Draught Fan:
Low-noise centrifugal fan as the standard configuration could reduce metal dust pollution caused byindoor metal processing, enhance the body health of employees.
Operation Cut System Software
1. Support CAD, AutoCAD,Coreldraw etc.
2. The professional cutting software which supports cutting path in dxf, plt and other graphic formats
3. Capable of setting cutting parameters in different layers
4. Combining joined lines to ensureautomatic splice of curve nodes
5. Smoothing fold lines to obtain smooth cuts
6. Optimized immediately after the completion of graphic design and thus improve the productivity
7.By making use of the compensation function of this professional cutting software, various cutting accuracy grades are obtained.
Nesting Software
1. It provides full-featured management capabilities and complete cutting solution
2. Its features of optimization and co-ordination for multiple sheets significantly improve thecomprehensive utilization rate
3. The advanced and practical function of cutting optimization improves the cutting efficiency and reduces the cutting cost considerably
4. It is with strong graphics processing and import capabilities and it supports all versions formats of CAD file
5.Abundant functions of aggregating statistics and reporting data for cutting materials
Our Services
1. Free installation, trial start and adjustment, training. But the machine quotation does not include the charges of our engineers in the buyer’s country if you want, and the buyer must take charge of all the expenditure including airplane tickets of our engineers when in the buyer’s country to do the service!
2. Warranty period is1 year. During the warranty period we shall reply to the call or Fax from the user for the machine faults (expect for faults caused by no abiding by the relevant operation regulations, or by force injury) within 24 hours.
